The Insert Edge Loop Tool lets you insert one or more edge loops across either a full or partial edge ring on a polygonal mesh. An edge loop is a path of polygon edges that are connected in sequence by their shared vertices. An edge ring is a path of polygon edges that are connected in sequence by their shared faces.

When you insert an edge loop, you are splitting the polygon faces associated with the selected edge ring. The Insert Edge Loop Tool lets you insert on or more edge loops across a full, partial, or multidirectional edge ring. The Insert Edge Loop Tool is useful when you want to add detail across a large area of a polygon mesh or when you want to insert edges along a user-defined path.

You can also modify the profile of the inserted edge loops creating features that protrude or recess on your polygon meshes along the inserted edge loop. Maintain position. The Maintain position options specify how new edges are inserted on the polygon mesh. When the Maintain position is set to Relative distance from edge default the dotted insert edge preview locator is positioned along the selected edge based on a percentage distance along the selected edge.

For example, if you click and then drag the selected edge to a location that is approximately halfway along the selected edge, the dotted preview locator appears approximately halfway between all of the other edges along the selected edge ring. When Maintain position is set to Equal distance from edge , the dotted insert edge preview locator is positioned along the selected edges at an absolute distance based on where you click on the first edge.

When the length of edges is highly variable, the tool uses the shortest edge to determine the maximum distance the preview locator can be moved. This option is useful if you want the new edges inserted at a specific distance from existing edges. For example, when you want to control any subsequent edge creasing you may perform on the mesh.

The distance the preview locator can move is limited by the length of the shortest edge on the associated edge ring. If the locator quickly snaps to either edge it may indicate a shorter edge in the edge ring that is limiting the placement.
